Explosion-Proof 3-Meter Wet Grinding Table
Maximizing Safety and Performance in Industrial Surface Finishing.
In high-stakes industrial environments, dust control isn’t just about cleanliness; it’s about safety, compliance, and product quality. CoatTech introduces our premier Explosion-Proof 3-Meter Wet Grinding Table, a robust, integrated solution engineered specifically for the most hazardous dust extraction challenges.
This downdraft table combines massive, three-meter workstation capacity with an intrinsic explosion-proof design and an ultra-efficient wet filtration system, ensuring your operators are protected and your facility meets the strictest environmental standards.
Key Performance Benefits
✅ Industry-Leading Dust Removal: Achieves an impressive 95% dust collection efficiency.
✅ Intrinsically Safe (IS) Design: The entire machine is built with explosion-proof components, making it ideal for processing conductive, combustible, or reactive metal dusts (e.g., aluminum, titanium).
✅ High-Volume Workstation: Spanning 3 meters, it comfortably accommodates up to three operators simultaneously, maximizing throughput without sacrificing safety.
✅ Durable stainless-steel construction (201 grade, 1.2mm thickness)
Detailed Product Features
1. Optimal Workstation Ergonomics
The expansive three-meter table surface is optimized for comfort and productivity. The built-in workstations are powered by two 1200mm explosion-proof lights for perfect visibility, even during precision finishing.
2. Fully Integrated Dust Capture & Filtration
The system pulls fine particles down through the table surface, targeting dust right at the source. The hazardous particulate matter is then captured in a high-efficiency wet scrub filtration system, neutralising fire risks.
3. Rear-Access Utility Core
The rear of the machine is a Masterclass in engineering, housing the essential filtration and safety components:
1.Water-Oil Separator: Essential for cleaning the recirculated water.
2.Dual Explosion-Proof Water Pumps (1.5kW): Redundant, high-power flow.
3.Filtration System: Utilizes both specialized Filter Bags and Steel Wire Filtration Mesh for multi-stage cleaning.
4.Safety Interlocks: Feature a low-water level automatic alarm with safety shutdown.
5.Precision Fluid Control: Includes Float Ball Valves and high-accuracy Liquid Level Detectors.
Technical Specifications
| Specification | Parameter | Details |
| Dimensions | 3000 * 1550 * 2100mm | Overall size |
| Work Surface Height | 750mm |
|
| Table Depth | 700mm |
|
| Material | Stainless Steel 201 (1.2mm Thick) | Durable construction |
| Workstations | Designed for up to 3 operators | Includes integrated tools |
| Lighting | 2x 1200mm Explosion-Proof Lights | Highly visible illumination |
| Integrated Tools | 3x Air Guns | Included |
| Auxiliary Power | 3x Explosion-Proof Sockets | 3+2 Configuration |
| Storage | 2x Storage Cabinets | Integrated organization |
| Dust Collection Efficiency | >95% | Industrial grade |
| Ventilation (Top Outlet) | Built for Direct Pipeline Connection | Discharge outdoors |
| Fan System | 2x Explosion-Proof Centrifugal Fans | Power: 4kW Airflow: 4500-5400 m³/h Air Pressure: 2120-1830 Pa |
| Fan Material | Cast Iron | Durable and heavy-duty |
| Water System | Wet Filter Media with Multi-Stage | Uses PVC pipeline, fittings, and nozzles |
| Safety Features | Floating Ball Valve, Liquid Level Detector | Features low-water alarm/shutdown |
| Pneumatics | Water-Oil Separator |
|
| Control System | Explosion-Proof Control Box (415V) | Controls fans and pumps |
Industrial 3m Wet Downdraft Grinding Table by CoatTech. Explosion-proof construction with 95% dust removal efficiency.
Triple-workstation design.Safe dust extraction for hazardous environments.
Here is the Youtube Link for your reference
https://www.youtube.com/shorts/JT4-9NKkCIQ
